Home > products > Galvanized Steel Coil > 0.12mm Cold Rolled Steel Q235 Hot Dipped Galvanised Coil

0.12mm Cold Rolled Steel Q235 Hot Dipped Galvanised Coil

Product Details

Place of Origin: Shandong China

Brand Name: ZGMC

Certification: ISO TUV SGS BIS CE

Model Number: Galvanize steel coil

Payment & Shipping Terms

Minimum Order Quantity: 3Tons

Price: Negotiable

Packaging Details: With iron sheet to pack the steel sheet and pallet .Also make the shipping marks on each bundles.

Delivery Time: 5-15days depend on the quantity

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,OA

Supply Ability: 5000Tons Per Months

Get Best Price
Highlight:

q235 galvanized sheet coil

,

0.12mm hot dipped galvanised coil

,

q235 hot dipped galvanised coil

Product Name:
Galvanize Steel Coil
Material:
Q235 Q345 Or According To Your Request
Technique:
Cold Rolled & Hot Dip Galvanized
Standard:
AISI, ASTM, BS, DIN, GB, JIS
Grade:
SPCC, SPCC- SD, DC01,DX51D Etc.
Thickness:
0.12-2.0mm
Width:
20-1250mm Or Required
Surface:
Zero Spangle / Mini Spangle / Regular Spangle / Big Spangle
Application:
Building & Construction,Household AppliancesAuto Panel; Interior Decorative Panel; Carriage Panel Etc.
Name:
0.12mm-2mm Cold Rolled Q235 Hot Dipped Galvanized Steel Coil
Product Name:
Galvanize Steel Coil
Material:
Q235 Q345 Or According To Your Request
Technique:
Cold Rolled & Hot Dip Galvanized
Standard:
AISI, ASTM, BS, DIN, GB, JIS
Grade:
SPCC, SPCC- SD, DC01,DX51D Etc.
Thickness:
0.12-2.0mm
Width:
20-1250mm Or Required
Surface:
Zero Spangle / Mini Spangle / Regular Spangle / Big Spangle
Application:
Building & Construction,Household AppliancesAuto Panel; Interior Decorative Panel; Carriage Panel Etc.
Name:
0.12mm-2mm Cold Rolled Q235 Hot Dipped Galvanized Steel Coil
0.12mm Cold Rolled Steel Q235 Hot Dipped Galvanised Coil
Product Name: Cold rolled Hot-dipped galvanize coil
Standard: AISI, ASTM, BS, DIN, GB, JIS, DIN-1623, EN-10130, JIS-G3141, etc.
Material: Q235 Q345 or according to your request
Grade: SPCC,SPCD,SPCE,DX51D  DX52D,DX53D
Coil weight: 3-10 ton or according to your request
Thickness: 0.12mm-2.0mm
Width: 20mm-1250mm or according to your request
Zinc coating: 60g/m² - 275g/m²
Surface Structure: Zero Spangle / Mini Spangle / Regular Spangle / Big Spangle
Surface Treatment: Passivation/skin pass/non-oiled/oiled
Technique: Cold rolled & Hot dip galvanized
Performance: Durable, anti-fingerprint
MOQ: 1 ton per size
Supply Ability: 5000t/month
Delivery Time: Within 15 days after receiving the pre-payment.
Export Packing: Standard Export Seaworthy Package.
Payment Terms: L/C at sight, T/T or Negotiable.









Galvanized steel is defined as a carbon steel sheet coated with zinc on both sides. There are two main processes used to produce galvanized steel: continuous hot dipping and electro-galvanizing. The hot dipping process consists of passing the steel through a bath of molten zinc, while the electro-galvanizing process consists of the application of zinc through electrolytic disposition. The result is a layer of zinc tightly adhering to the base metal through an iron-zinc bonding layer.





Zinc coating is one of the most effective and economical methods of protecting bare steel from a corroding environment. The zinc not only serves as a barrier between the steel and the environment, but it will also sacrifice itself to protect the underlying steel sheet. Sacrificial or galvanic protection occurs when two dissimilar metals are in contact and coupled with water and oxygen. Zinc corrodes preferentially to the iron in steel. This protection prevents corrosion of the steel at areas not covered with zinc. Thus, the spread of corrosion from cut edges, drill holes, etc. is minimized.





Advantages of Galvanized Steel

The main advantage of galvanized steel is its corrosion resistance. The zinc coating serves as a barrier between the steel and the environment and will sacrifice itself in order to protect the underlying steel; Meaning the zinc will degrade much sooner than the steel itself. Additionally, it offers good processability and formability.





Galvanized Steel Coil Material Types

  • Commercial Steel (CS Types A, B, and C)
  • Forming Steel (FS Types A and B)
  • Deep Drawing Steel (DDS Types A and C)
  • Extra Deep Drawing Steel (EDDS)
  • Structural Steel (SS) – further designated by Grades (33,37,40,50,80)
  • High Strength Low Alloy Steel (HSLAS)





Typical Galvanized Steel Coil Applications:

  • ♦Exterior building products
  • Ductwork
  • HVAC products
  • Flashing
  • Roofing
  • Doors
  • Sashes







Specification for JIS G3141.



JIS G3141 SPCC Cold Rolled Coil
C Mn P S
≤0.15 ≤0.60 ≤0.100 ≤0.050
Yield Strength Mpa Tensile Strength Mpa Elongation(Thickness)
140~280 270 0.25-2.5mm ≥2.5mm
34 34
JIS G3141 SPCD Cold Rolled Coil
C Mn P S
≤0.12 ≤0.50 ≤0.04 ≤0.040
Yield Strength Mpa Tensile Strength Mpa Elongation(Thickness)
240 270 0.25-2.5mm ≥2.5mm
30-40 41
JIS G3141 SPCE Cold Rolled Coil
C Mn P S
≤0.15 ≤0.45 ≤0.030 ≤0.030
Yield Strength Mpa Tensile Strength Mpa Elongation(Thickness)
220 270 0.25-2.5mm ≥2.5mm
32-42 43
JIS G3141 SPCF Cold Rolled Coil
C Mn P S
≤0.08 ≤0.45 ≤0.030 ≤0.030
Yield Strength Mpa Tensile Strength Mpa Elongation(Thickness)
≤220 ≥270 0.25-2.5mm ≥2.5mm
40 45
JIS G3141 SPCG Cold Rolled Coil
C Mn P S
≤0.02 ≤0.25 ≤0.020 ≤0.020
Yield Strength Mpa Tensile Strength Mpa Elongation(Thickness)
≤210 270 0.25-2.5mm ≥2.5mm
40 45









0.12mm Cold Rolled Steel Q235 Hot Dipped Galvanised Coil 0

0.12mm Cold Rolled Steel Q235 Hot Dipped Galvanised Coil 1



0.12mm Cold Rolled Steel Q235 Hot Dipped Galvanised Coil 2

0.12mm Cold Rolled Steel Q235 Hot Dipped Galvanised Coil 3













FAQ:



Q1. What are your company's main products ?

A1: Our main products are stainless steel & Galvanize coils, plate/sheet, round/square pipe etc.



Q2. How do you control quality ?

A2: Mill Test Certification is supplied with shipment, Third Party Inspection is available. and we also get ISO,SGS,Alibaba Verified.



Q3. What are the advantages of your company ?

A35: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.



Q4: What is the terms of packing?

A3: generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers requirement.



Q5:What is your delivery time?

A4: For stocks, we could transport the goods to loading port within 7 days after we received your deposit

For production period, it usually takes about 15 days-30 days after receiving the deposit.



Q6. Can you provide sample ?

A7: We can provide the samll samples in stock for free, as long as you contact us.

Customized samples will take about 5-7days.



Q7. How many coutries you already exported ?

A6: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt, Turkey, Jordan,India,Thailand, Vietnam, South Korea etc.
