Product Details
Place of Origin: Shandong China
Brand Name: ZGMC
Certification: ISO TUV SGS BIS CE
Model Number: Stainless Steel Plate
Payment & Shipping Terms
Minimum Order Quantity: 3Tons
Price: Negotiable
Packaging Details: With iron sheet to pack the steel sheet and pallet .Also make the shipping marks on each bundles.
Delivery Time: 5-15days depend on the quantity
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram,OA
Supply Ability: 5000Tons Per Months
Name: |
Stainless Steel Sheet |
Standard: |
JIS, ASTM, DIN, EN, AISI,GB,etc |
Edge: |
Mill Edge Or Cutting As Required |
Surface: |
2B,BA,No.1,No.4,No.8,8K,mirror,sand Blast,Hair Line, Etc |
Application: |
,foodstuff,chemical Industry,construction, Electric Power,nuclear,energy |
Technique: |
Cold Rolled,hot Rolled |
Thickness: |
0.5-100mm |
Width: |
600-1500mm Or As Requried |
Length: |
Upto 8000mm Or As Requried |
Tolerance: |
Standard Tolerance |
Name: |
Stainless Steel Sheet |
Standard: |
JIS, ASTM, DIN, EN, AISI,GB,etc |
Edge: |
Mill Edge Or Cutting As Required |
Surface: |
2B,BA,No.1,No.4,No.8,8K,mirror,sand Blast,Hair Line, Etc |
Application: |
,foodstuff,chemical Industry,construction, Electric Power,nuclear,energy |
Technique: |
Cold Rolled,hot Rolled |
Thickness: |
0.5-100mm |
Width: |
600-1500mm Or As Requried |
Length: |
Upto 8000mm Or As Requried |
Tolerance: |
Standard Tolerance |
High Quality Surface 0.5mm Thickness Super Duplex Stainless Steel Sheets
Sheet, Plates & Coils
RANGE
0.1 mm to 100 mm thick upto 2500 mm width & upto 8000 mm length available with NACE MR 01-75s.
Stainless Steel
ASTM / ASME SA 240 304 , 304L , 304H, 309S , 309H, 310S , 310H , 316 , 316H , 316L , 316 TI , 317 , 317L , 321 , 321H , 347 , 347 H , 409 , 410 , 410S , 430
Duplex Steel
ASTM / ASME SA 240 UNS NO. S 31803 , S 32205 , S 32550 , S 32750 , S 32760.
|
Product name
|
stainless steel sheet
|
|
Grade
|
201,202,304,304L,309, 309S,310S,316,316L,316Ti,317L,321,347H,409,409L,410,
410S, 420(420J1, 420J2), 430, 436, 439, 441, 444, 446
etc. |
|
Thickness
|
0.3mm-6mm(cold rolled),3mm-100mm(hot rolled)
|
|
Width
|
1000mm,1219mm(4feet),1250mm,1500mm,1524mm(5feet),1800mm,2000mm or
as your requirements.
|
|
Length
|
2000mm,2440mm(8feet),2500mm,3000mm,3048mm(10feet),5800mm, 6000mm
or as your requirements.
|
|
Technology
|
cold rolled,hot rolle
|
|
Delivery time
|
7-10 days after your deposit, or according the quantity
|
|
Package
|
Water proof paper+metal pallet+Angle bar protection+steel belt or as requirements
|
| Applications |
Architectural decoration, luxury doors, elevators decorating, metal tank shell, ship
building,decorated inside the train, as well
as outdoor works, advertising nameplate, the ceiling and cabinets, aisle panels, screen, the tunnel project, hotels, guest houses,
entertainment place,kitchen equipment, light industrial and so on. |
| AISI TYPE |
C | Si | Mn | P | S | Ni | Cr. | Mo |
| Austentic St. Steel | ||||||||
| 303 | 0.15 | 1.00 | 2.00 | 0.20 | 0.15 | 8.00 10.00 |
17.00 19.00 |
|
| 304 | 0.06 | 1.00 | 20.00 | 0.045 | 0.030 | 8.00 10.00 |
18.00 20.00 |
|
| 304L | 0.03 | 1.00 | 2.00 | 0.045 | 0.030 | 11 | 18 | |
| 316 | 0.07 | 1.00 | 2.00 | 0.045 | 0.030 | 11 | 18 | 2.00 3.00 |
| 318L | 0.03 | 1.00 | 2.00 | 0.045 | 0.030 | 13 | 18 | 2.00 3.00 |
| 317 | 0.06 | 1.00 | 2.00 | 0.045 | 0.030 | 13 | 18 | 3.00 4.00 |
| 317L | 0.03 | 0.50 | 1.75 | 0.045 | 0.030 | 14 | 19 | 3.00 3.00 |
| 321 | 0.08 | 1.00 | 2.00 | 0.45 | 0.030 | 11 | 18 | |
| 325 | 0.25 | 2.00 | 0.60 | 0.045 | 0.030 | 19.00 23.00 |
10 | |
| 347 | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 11 | 15 | |
| Heat Resisting Steel | ||||||||
| 309 | 0.20 | 1.00 | 2.00 | 0.045 | 0.030 | 12.00 15.00 |
22.00 24.00 |
|
| 310 | 0.25 | 1.50 | 2.00 | 0.045 | 0.030 | 19.00 22.00 |
24.00 26.00 |
|
| Ferritic St. Steel | ||||||||
| 405 | 0.08as | 1.00 | 1.00 | 0.045 | 0.030 | - | 11.50 14.50 |
|
| Martensetic St. Steel | ||||||||
| 410 | 0.12 | 1.00 | 1.00 | 0.040 | 0.030 | - | 12.5 | |
| 416A | 0.12 | 1.00 | 1.25 | 0.060 | 0.15 | - | 12.5 | |
| 420 | 0.23 | 1.00 | 1.00 | 0.040 | 0.030 | - | 12.5 | |
| 431 | 0.20 | 1.00 | 1.00 | 0.040 | 0.030 | 2.00 | 16.00 | |
| 8K mirror | 316 stainless steel sheet #8 mirror has a non-directional finish that virtually looks like a mirror. It comes with a double layer of PVC film to protect the mirror finish during fabrication and installation. |
| BA finish | The 316 stainless steel bright annealed (BA) finish is cold rolled stainless steel that is annealed in a controlled atmosphere to retain a highly reflective finish. It has a PVC film on one side to help protect against scratching during fabrication and installation. |
| #4 finish | 316 stainless steel sheet #4 finish is the brushed finish commonly seen on kitchen appliances and backsplashes. It has a PVC film on one side to help protect against scratching during fabrication and installation. |
| 2B finish | 316 stainless steel 2B finish is a mill finish, which is smooth and NOT the brushed finish commonly seen on kitchen appliances.It may or may not have a protective film on one side to prevent scratching. |
Jiangsu Hengdali Steel Industry Co., Ltd. is a professional and reputable steel manufacturer and exporter from Wuxi, China. We have been in this line for more than 15 years. We have steel factories both in Liaocheng and Wuxi which are well-known as the two biggest steel production and distribution centers in China. We can provide stainless steel sheets,coils,tubes,bars,profiles as well as Nickel Alloy and Hastelloy Alloy.
Our steel service capabilities include slitting, shearing, blanking, leveling, degreasing and brushing and metallurgical support. Our products are mainly exported to Europe, America, Southeast Asia, the Middle East and other countries and regions and widely used in construction, bridge, car manufacturing, electrical installation and mining fields. We have won great recognition and reputation for our good credibility and services during the past 15 years.In the future, we will move on to provide more and better steel products for our client on the belief of High Quality, Big Honesty and Strong Reliability.
Q:What kind of work does your company do?
A:Our company is a professional manufacturer.
We mainly produces stainless steel plate/pipe/coil/round bars,as well as aluminum plate/pipe/coil/bar
Q:What are the advantages of your company?
A:
(1): Prime quality and reasonable price.
(2): Wide excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Trial order can be done in one week.
(6): Samples can be provided as your requirements.
Q:What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance based on BL copy or LC at sight.
If you have another question, please contact us as below
Q:What about your price?
A:Our price is very competitive because we are a factory.
Pls feel free to contact us if you are interested in our products.
Q:How long is your delivery time?
A:Different products have different delivery time.The products will be delivered as soon as possible on the basis of the quality assurance.Usually the delivery time is within5 days after we received your deposit.
