BA Surface Nickel Alloy Pipe Hot Forging Abrasion Resistant Steel K500

Place of Origin China(mainland)
Brand Name TISCO
Certification SGS,BV
Model Number Stainless Steel Plate
Minimum Order Quantity 1 Ton
Price Negotiable
Packaging Details in bundle, plastic bags, thin film, wooden pallet, standard seaworthy export packing or as customer demands
Delivery Time 10-15 days after deposit
Payment Terms L/C, T/T, Western Union, MoneyGram, D/P
Supply Ability 5000 Ton/Tons per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Grade Pure Nickel Standard GB,AISI,ASTM,DIN,EN,SUS,UNS Etc
Model Number Monel 400/K500/R405 Type Sheet /Plate/Bar/ Tube/Pipe
Technique Hot Forging Or Cold Treatment Application Industry
Size Customzied Surface 2B/BA/NO1/4K/8K
High Light

Monel 400 Nickel Alloy Pipe

,

K500 Nickel Alloy Pipe

,

Abrasion Resistant Steel K500

Leave a Message
Product Description



Prime Quality Alloy Steel Sheet Plate Monel 400 405 K500 600 Nickel Alloy Tube Pipe Plate Bar





Product Description:



Monel 400 is a kind of corrosion resistant alloy with the largest dosage, the widest application and excellent comprehensive performance. This alloy has excellent corrosion resistance in hydrofluoric acid and fluorogas medium, and also has excellent corrosion resistance to hot concentrated lye. It is also resistant to corrosion of neutral solution, water, seawater, atmosphere and organic compounds. An important characteristic of this alloy is that it generally does not produce stress corrosion crack and has good cutting performance.



Chemical Composition (%) of  Nickel Copper Alloy Sheet:

Item Ni% Cu% Al% Ti% Fe% Mn% S% C% Si%
Monel 400 ≥63 28-34 2.3-3.15 0.35-0.85 Max2.5 Max2 Max0.024 Max0.3 Max0.5
Monel k500 ≥63 27-33 2.3-3.15 0.35-0.85 Max2 Max1.5 Max0.01 Max0.25 Max0.5





Mechanical Properties of Monel400 Sheet:



Tensile strength yield strength elongation
σb≥450Mpa σb≥170Mpa δ≥30%





Standard referance:



Monel 400 Bar/Rod Forging Pipe Sheet/Strip Welding Wire
Standard ASTM B865 AMS4676 ASTM B865 ASTM B564 ERNiCu-7





Product details:



Product Name Monel 400 405 k500 600 Nickel Alloy Tube Pipe Palte Bar
Material Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
Shape

Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,

Bar,Pipe,Sheet

Specification Wire: 0.01-10mm
Strip: 0.05*5.0-5.0*250mm
Bar: φ4-50mm;Length 2000-5000mm
Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
Product
Characteristics
1.According to the preparation process can be divided into deformation superalloys,
casting superalloys and powder metallurgy superalloys.
2.According to the strengthening mode, there are solid solution strengthening type, precipitation
strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc..
Inspection ISO,SGS,BV and so on.
Application High temperature components such as turbine blades, guide vanes, turbine disks, high pressure
compressor disks,machine manufacturing
and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines




Product package:

The wear resistant steel sheet will be packed in seaworthy packing such as steel strips bundles. If you have any special requests on this, please let us know advanced. We will refer to your email kindly.
1).20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) Max length is 5.8m, max weight is 25 tons.
2).40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) Max length is11.8m, max weight is 26 tons.
3).40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)


 Our Advantage:

1. Honest business with competitive price
2. Professional service on export process
3. Good payment term
4. Good reputation en every market
5. Quality assurance
6. Always a pre-production sample before mass production
7. Always final inspection before mass production




Product&Our Company Show:





BA Surface Nickel Alloy Pipe Hot Forging Abrasion Resistant Steel K500 0

BA Surface Nickel Alloy Pipe Hot Forging Abrasion Resistant Steel K500 1

BA Surface Nickel Alloy Pipe Hot Forging Abrasion Resistant Steel K500 2

BA Surface Nickel Alloy Pipe Hot Forging Abrasion Resistant Steel K500 3


BA Surface Nickel Alloy Pipe Hot Forging Abrasion Resistant Steel K500 4


Packing&Shipping:


BA Surface Nickel Alloy Pipe Hot Forging Abrasion Resistant Steel K500 5

Wear Resistant Steel Plate
